| Frequency: |
| Range |
5 to 890 MHz |
| |
|
| Accuracy |
10 ppm @ 25°C (77°F) |
| |
20 ppm over temp |
| Tuning Resolution |
25 kHz |
| Level
Measurement: |
| Range |
-20 to +50 dBmV |
| Resolution |
0.1 dB |
| Accuracy |
±0.75 dB Flatness, |
| |
±0.75 dB Linearity @
25°C (77°F) |
| Digital Average Power
(optional) |
± 2.0 dB (typical) |
| Scan Mode: |
| Number of Channels |
120 |
| Scan Rate |
Approximately 6
carriers/second |
| Leakage
Mode: |
| Level Measurement |
|
| Input
Sensitivity (with HD-1 dipole or VMA-3 mag mount) |
| Video Detection |
From 1 µV with LT1000 |
| |
Leakage Tagger
activated |
| |
(121 to 133.2625
MHz). |
| CW Detection |
From 0.5 µV typical
with LT1000 |
| |
Leakage Tagger
activated |
| |
(121 to 133.2625
MHz). |
| Measurement |
From 1.4 µV (115 to
140 MHz). |
| Range |
0.5 to 2,000 µV (at
input connector) |
| |
|
| Accuracy |
| Measurement |
±1.5 dB @ 25°C (77°F) |
| Find & Fix |
±2.25 dB @ 25°C
(77°F) |
| |
|
| Tuning Carrier |
|
| Frequency Range |
115 to 140 MHz range
(Video) |
| Accuracy |
10 ppm @ 25°C (77°F); |
| |
20 ppm over temp. |
| Resolution |
25 kHz |
| Tagger modulation for
leakage |
Modulation frequency |
| |
5 to 25 Hz |
| Operating: |
| Temp. Range |
-10 to +50°C (14 to
122°F); |
| |
±3 dB drift, -10 to
+50°C |
| Water Resistance |
Meets or exceeds
MIL-STD-810D |
| |
(Method 506.2) |
